Art. No.

Thread Size

Wire
mm

D1
mm

D2
mm

L3
mm

L1
mm

L2
mm

KG/100

B.L.KG.

ZK01-0103-0402

M4

2

2.2

4.8

24

145

197

2.3

500kg

ZK01-0103-0502

M5

2

2.2

5.5

32

178

238

4

800

ZK01-0103-0525

M5

2.5

2.7

5.5

32

178

238

4

800

ZK01-0103-0532

M5

3.2

3.5

6.35

39

184

244

4.5

800

ZK01-0103-0603

M6

3

3.3

6.35

39

204

274

7

1250

ZK01-0103-0632

M6

3.2

3.5

6.35

39

204

274

7

1250

ZK01-0103-0604

M6

4

4.3

7.5

45

224

294

7.8

1250

ZK01-0103-0804

M8

4

4.3

7.5

45

235

305

12

2350

ZK01-0103-0805

M8

5

5.3

9

52

249

319

13.5

2350

ZK01-0103-1005

M10

5

5.3

9

52

270

355

22.5

3500

ZK01-0103-1006

M10

6

6.4

12.6

64

300

385

30

3500

ZK01-0103-1206

M12

6

6.4

12.6

64

330

445

43

5100

ZK01-0103-1208

M12

8

8.4

16

80

370

480

55

5100

ZK01-0103-1407

M14

7

7.4

14.2

70

365

485

57

5900

ZK01-0103-1608

M16

8

8.4

16

80

418

548

92

8000

ZK01-0103-1610

M16

10

10.5

18

90

438

568

100

8000

ZK01-0103-2010

M20

10

10.5

18

90

465

620

145

13000

ZK01-0103-2012

M20

12

12.6

20

105

495

650

151

13000

ZK01-0103-2214

M22

14

14.7

25

140

645

820

378

17000

ZK01-0103-2416

M24

16

16.9

28

160

745

980

553

20000

ZK01-0103-2719

M27

19

20

34.5

200

880

1115

801

27000

ZK01-0103-3022

M30

22

23.2

40.5

230

985

1240

1179

31000

ZK01-0103-3626

M36

26

27.5

46

280

1130

1400

1589

43000
